Bulb R7S 118mm 1200lm COB 12W Chip

Name: LED Bulb R7S 118mm COB 12W | LED Bulbs
Brand: Barcelona LED
SKU: B1375
Price: 9.45 EUR
Availability: OutOfStock

SKU:B1375-BN

€9.45 Tax included

Colour temperature

Warm white 3000K
Neutral white 4000K
Cool white 6000K

Out of stock

Data sheet

R7S 118mm LED bulbs with 12W power. Direct connection to 230V (no transformer required). The LEDs integrate COB technology of high luminous efficiency 1200 lumens. Replaces 118mm halogen lamps with R7S connection up to 100W, with savings that can exceed 85% in energy consumption. Long life of approximately 30,000 hours. 360 degree opening angle. High efficiency and high quality LED bulb.

12W
230V
Ø20x118mm
360º

Shipping to Africa available

public

For any shipping requests to Africa, please contact our sales department at: comercial@barcelonaled.com

R7S LED Bulb R7S LED Chip COB 118mm 12W

With R7S LED bulb you will get more brightness and energy saving, you can place them in all kinds of luminaires that have R7S connectors, it is not recommended to install in closed luminaires. These R7S LED bulbs are as bright as 60W halogen bulbs, easy to install with a standard R7S 118 base. It has a wide projection angle of 360°, can illuminate every corner in all directions, and a power of 12W for maximum brightness.

It only consumes 10% to 15% of the energy, allowing you to easily save up to 85% of your energy bill. Selectable in different color temperatures: warm white, 3000ºK, neutral white, 4000ºK and cool white 6000ºK. Minimum heat emission and minimum consumption.

bombillas LED R7S

The new COB LED bulbs offer high luminous efficiency with a brightness of 1200 lumens. Thanks to the COB technology, the bulb has a uniform light effect. Lead and mercury free, no UV or IR radiation. Designed with high transmittance glass and suitable for multiple applications such as LED lamps, floor lamps, chandeliers, wall lamps, table lamps, etc.

With high resistance to shock and vibration due to its IP40 degree of protection. Dimensions of Ø20x118mm. Unique design to ensure constant lamp temperature.

dimensiones bombilla r7s

Bombillas LED

Advantages of R7S LED Bulb 12W

- Automatic ignition

- Vibration and shock resistant

- Low heat emission

- High light output

- Environmentally friendly, no heavy metal and ultraviolet emission

Applications of R7S LED Bulb

You can place it in the lamps that have R7S connection, such as:

- Floor lamps

- Ceiling lamps

- Wall sconces

bombilla led r7s cob

Power (W)

Kelvin (K)

3000
4000
6000

Lifetime (h)

30000

IP40

Frequency (Hz)

50 - 60

Hue

Cool white
Neutral white
Warm white

Efficiency (Lm/w)

100

CRI

80-85

LED Type

COB

Driver

Internal

Energy efficiency class

A+ (2021)

Certificates

CE
ROHS

Warranty

According to legal guarantee: 2 years

Attachments

Product data sheet

Questions

P: Question:	In the description of this bulb it says that it is not recommended to install it in an enclosed luminaire, why is it not?

R: Answer:	The temperature given off by this model is quite high, enclosing the bulb will increase the possibility of premature failure of the LEDs.

P: Question:	Good morning, is the light dimmable?

R: Answer:	This model is not adjustable.

P: Question:	The most powerful R7S led bulbs are 12 w ? I want to change a halogen 150 for a led bulb that should I put ? Buying a bulb of 7 or 8 euros how much does it cost me the transport ? Thank you very much for your attention.

R: Answer:	This model is 1300lm. replaces up to about 100W (depends on models). You can see the (shipping and delivery condition) at the end of the web.

P: Question:	The diameter indicated in the specifications is not correct. It says it measures 28mm, I bought two and it actually measures 16mm. You should modify it. Greetings.

R: Answer:	If the measurement is of a previous model, the diameter is 16mm with a maximum width in the center of 20mm (the glass protrudes).

P: Question:	I recently bought two bulbs (B1375BF) R7S 118 mm 120lm chip COB 12W. my question, is it normal that when I turn them on especially at the beginning they flicker? and they don't go in any dimmable bulbs. thanks

R: Answer:	If they are connected directly to the 230Vac mains supply at each terminal of the R7S, without any ballast or electronic equipment from previous systems, and without any wall or lamp dimmer, they should not flicker. Make sure that the installation is OK and does not make the same fault elsewhere. If everything is correct you can contact comercial@barcelonaled.com to process warranty.

P: Question:	I need to replace halogen bulbs in a lamp with LED bulbs. Bulb R7S 118mm 1200lm Chip COB 12W Reference:B1375-BN this or similar is dimmable? Since for decoration should be able to dim and intensify the lighting. Thank you very much

R: Answer:	The COB models are not adjustable, you should see other models R7S example ref. 57879700

P: Question:	Good evening, I was wondering if you had R7S 118mm 100w LED bulbs. Thank you

R: Answer:	The highest wattage available is 12W LED. Here's a link to the R7S bulbs available: https://www.barcelonaled.com/pt/lampadas-led/lampadas-lineares-led-r7s/

P: Question:	My floor lamp has a ponteciometer to increase illumination. This lamp is possible its incorporation????

R: Answer:	The dimmer must be prepared for LED luminaires with small power loads, otherwise there may be flickering at minimum dimming.

P: Question:	I need to know if these bulbs can be connected to a dimmer, i.e. if they are dimmable. Thank you. Thank you.

R: Answer:	They allow some dimming, but it depends on whether the dimmer is prepared for LED luminaires with small power loads, otherwise there may be flickering at minimum dimming.
