220V AC COB LED Strip - 10W/m - 12mm - IP67 - 20 meters

Name: 220V AC COB LED Strip - 10W/m - 12mm - IP67 - 20 meters
Brand: Barcelona LED
SKU: B1536-20
Price: 129.99 EUR
Availability: InStock

SKU:B1536-20-BN

€129.99 Tax included

Colour temperature

Cool White
Neutral White
Warm White

Out of stock

Data sheet

The COB LED strip stands out for its bright and uniform lighting, with no shadows or visible light spots, unlike traditional LED strips.

It has a total width of 12mm (PCB: 10.5mm) and its great flexibility allows easy installation in any space. It can be cut every 50 cm and has a CRI>90.

Incorporating COB technology, it has a high luminous efficacy of 100lm/W, with a density of 288 LED/meter.

Due to its IP67 protection rating , it's suitable for outdoor installation.

It's dimmable and available in warm white (2700K), neutral white (4000K) and cool white (6000K).

Shipping to Africa available

public

For any shipping requests to Africa, please contact our sales department at: comercial@barcelonaled.com

This LED strip incorporates COB technology, which allows it to emit a continuous light without visible points. Especially recommended when homogeneous illumination is desired, to work with reflective surfaces or to use transparent diffusers.

With a luminous intensity of 10W per meter, this strip provides exceptional brightness, superior to conventional LED strips.

The LED strip comes in a roll of 20 meters and allows cuts every 50cm, according to the indicated marks. It incorporates 3M self-adhesive on the back to adhere to the desired surface.

For its correct operation, it requires a rectifier that converts alternating current into direct current (Compatible reference: B1536-CI-EU).

In addition, for installation, it's recommended to use the specific connectors corresponding to our products: B1536-TT (strip-to-strip connector), B1536-CTT (strip-to-strip connector with cable) and B1536-L (90º connector).

Product features:

Voltage: 220V AC
Efficacy: 100lm/W
Power: 10W/m
Beam angle: 120°.
Dimmable
Total width: 12mm
PCB width: 10.5mm
Cut distance: 500mm
IP67: outdoor use
Strip length: 20 meters
LED chips: COB (288 LED/m)
Available in shades: warm white (2700K), neutral white (4000K) and cool white (6000K)
Dimensions: 12x20000mm

Please note that certain technical characteristics such as power or efficacy may vary according to the color/shade of the product. For further information, please consult the attached test reports in the "Downloads" section, or contact our sales advisors.

Nominal Voltage (V)

220 - 240 V/AC

Power/m (W/m)

Kelvin (K)

2700
4000
6000

Beam angle (º)

120

IP67

Dimensions (mm) Lxlxh

12x20000mm

Hue

Cool white
Neutral white
Warm white
