LED Strip 24V-DC 96W 12mm RGBW IP20 (SMD5050) 5 meter roll

SKU:B1548-RGBW
Has superado el límite de unidades
In stock 2143 units
Data sheet

RGBW LED strip at 24V-DC 96W (300 SMD5050 chips) PCB 12mm 5 meter coil, cut every 10cm. This strip offers us the possibility to choose any color of the RGB light spectrum but we can also shade it to cool white colors (W = White). This is the meaning of RGBW, thanks to it we can play with a wide range of colors looking for the most suitable depending on the time and place, it is one of our most versatile strips !!!

  • 24V-DC
  • 96W
  • IP20
  • RGBW
  • 120º
  • Cut 10cm
Shipping to Africa available
public
For any shipping requests to Africa, please contact our sales department at:  comercial@barcelonaled.com

RGBW 24V LED Strip offers you infinite color combinations.

The RGBW LED strip is one of the most technologically advanced and highest quality strips in our catalog. It incorporates cold white light diodes in this case, (there is also a warm white LED strip RGBWW), which allows you to use the strip as decorative or ambient, if we use colored light, and can even shade that color to cooler tones thanks to its W option. In the case you just want to illuminate is also possible thanks to its cold light diodes, so you get a very powerful light in cool white tones.

Characteristics and installation of RGBW strips:

It is a very powerful strip as it offers us a total of 96W along its 5 meters and 300 SMD5050 chips, so each meter has a power of 19.2W/mt. and 60 chips. It offers us approximately 60 lumens for each watt of consumption, so if we make the complete installation of the 5 meters we would get about 5760 lumens.

The steps to follow for the correct installation of the RGBW LED strip is exactly the same as for any other LED strip, the only difference is that we must use a specific controller for the control of white both to illuminate in cool white tones and to shade the RGB colors.

In our LED lighting store we have two types of RGBW controllers (also suitable for RGBWW strips): a handheld controller and a recessed touch controller. It is also essential the RGBW receiver as they work by radio frequency and a 24V power supply suitable for the power of the installation to be performed. We also have specific cables for RGBW/RGBWWW strips and connectors.

We cannot forget that for a perfect installation of our LED strips is highly recommended the use of aluminum profiles for LED strips for better heat dissipation and help to extend the life of the LED strip. That is not its only advantage, as you will get a premium finish and have different diffusers to diffuse the light as needed. And to incorporate it to the profile is very simple and fast thanks to the fact that the back of the strip has a 3M adhesive.

Applications of RGBW LED strip:

- They are ideal for lighting and decoration of music bars, discos, restaurants, hotels.

- Store lighting and business lighting, to attract attention in shop windows or indoors, in addition to lighting.

- Home lighting and decoration.

2018-06-02
Nominal Voltage (V)
24V-DC
Power (W)
96
Power/m (W/m)
19,2
Lumens (Lm)
5760
Beam angle (º)
120
Lifetime (h)
25000
IP
IP20
Dimensions (mm) Lxlxh
5000x12
Frequency (Hz)
50 - 60
Hue
RGB-W
Efficiency (Lm/w)
60
CRI
80-85
LED Type
SMD 5050
Dimmable
Yes
No. of chips/metre
60
Track width (mm)
12
Cutting distance (mm)
100
Use Outdoor
No
Adhesive
3M
Energy efficiency class
A++ (2021)
Certificates
CE
ROHS
Warranty
According to legal guarantee: 2 years
Barcelona LED

Questions

P: Question: I want to connect 5 meters of this LED strip to your "24V/100W/4A" power supply.

My question is if I can connect them in parallel to the power supply or should they be in series or mixed. What is the best performance and best duration to be connected 12 hours a day?
It is for the manufacture of some store displays with 5 shelves each display.

Thanks
Xavi
R: Answer: This strip model needs a RGBW controller like the SR-1009FA + SR-2819S between the source and the RGBW LED strip.
P: Question: Quin IC porta integrat el led?
R: Answer: This model is not an IC chip strip, it is an RGBW model with an SMD5050 LED.
P: Question: An A.F. with 24v 5 A 125W output is sufficient.
Apart from the controller, logically
R: Answer: For the 5m coil you must have a power supply of at least 24Vdc and 96W.
P: Question: Good afternoon, what is the best LED strip for Profile for LED strip for stairs 65X27.5 mm?
R: Answer: We have 24V LED strips that can be connected up to 10m consecutively: https://www.barcelonaled.com/pt/fitas-led/fitas-led-24v/
We have 12V LED strips: https://www.barcelonaled.com/pt/fitas-led/fitas-led-12v/
