Switching power supply 12V 300W
SKU:B1563-300
€37.95
Tax included
Shipping to Africa available
For any shipping requests to Africa, please contact our sales department at: comercial@barcelonaled.com
Switching power supply 12V 300W 25A IP20
The 300W switching power supply is mainly made to power 12V-DC LED strips, as well as any other device or luminaire with 12V-DC working voltage, as long as it does not exceed the maximum power. For all kinds of uses: professional, domestic, commercial, office, catering, etc.
The 12V power supply has a switch on the side to select the input voltage in 115V-AC or 230V-AC and an output voltage of 12V-DC that can be adjusted over ±20%, compensating the voltage drop between the power supply and the consumption point.
Perforated sheet metal housing protecting the power supply from overloads, overvoltages, etc. Power supply with compact dimensions of 200x113x50mm. Input voltage range 115~230V. ±20%. Output voltage 12V-DC with a maximum amperage of 25A.
Technical Specifications.
✔ Voltage range: 115~230V ±20%.
✔ Frequency: 50 Hz.
✔ O utput voltage: 12V-DC.
✔ O utput power: 300W.
✔ O utput amperage: 25A MAX.
✔ Degree of protection: IP20.
✔ Dimensions: 200x113x50mm.
✔ O vervoltage, short circuit and overheating protection.
Nominal Voltage (V)
110 - 220
Power (W)
300
Lifetime (h)
25000
IP
IP20
Frequency (Hz)
50 - 60
Output voltage (V)
12V
Material
Plastic
Use Outdoor
Yes
Temperature range
-20°C ~ +40°C
Frequency of use
Normal
Energy efficiency class
A+ (2021)
Certificates
CE
ROHS
ROHS
Warranty
According to legal guarantee: 2 years
Maximum intensity (A)
25
