DALI dimmable DT6 Single color driver 220-240V - Output 6-58V DC - 250-700mA - 25W
DALI dimmable DT6 Single color driver 220-240V - Output 6-58V DC - 250-700mA - 25W
DALI dimmable DT6 Single color driver 220-240V - Output 6-58V DC - 250-700mA - 25W

DALI dimmable DT6 Single color driver 220-240V - Output 6-58V DC - 250-700mA - 25W

SKU:SRP-2305N-25CC250-700
Has superado el límite de unidades
In stock 55 units
Data sheet

DALI dimmable DT6 Driver, single color 220-240V, 25W. Converts alternating current into direct current to power monochrome LED luminaires such as panels, downlights, and LED ceiling fixtures.

It offers precise dimming from 0.01% to 100%, no flicker, high power factor, and energy efficiency.

It incorporates protection against short circuit and overload.

Shipping to Africa available
public
For any shipping requests to Africa, please contact our sales department at:  comercial@barcelonaled.com

The DALI Driver is an innovative and versatile device. It's manufactured with high quality components and features a robust design that guarantees a long product lifetime.

It's DALI-2 certified and has an integrated DALI-2/Push interface that ensures reliable and accurate communication.

Its NFC function allows precise adjustment of the output current, with 0.1 mA increments in the range of 250 to 700 mA.

It also features a high power factor and low harmonic distortion, ensuring stable and high-quality power supply.

It ensures constant, flicker-free light, with extremely accurate dimming down to 0.01%.

It's highly compatible with universal DALI masters supporting DT6 commands, simplifying integration into existing systems.

Product features:

  • Input voltage: 220-240V AC
  • Output voltage: 6-58V DC
  • Power: 25W
  • Current: 250-700mA
  • Indoor use: IP20
  • Dimensions: 135 x 35 x 20mm

Nominal Voltage (V)
220 - 240 V/AC
Maximum power (W)
25
IP
IP20
Control system
DALI
Output voltage (V)
6-58 Vdc
Colour control
Monocolor
Use Outdoor
No
Certificates
CE
ROHS
Warranty
5 years
Output current mA
250-700mA
SUNRICHER
