IP44 photoelectric twilight light sensor
SKU:S1100
€9.99
Tax included
Shipping to Africa available
For any shipping requests to Africa, please contact our sales department at: comercial@barcelonaled.com
IP44 photoelectric twilight sensor for indoor / outdoor use.
This photoelectric brightness sensor, also called photocell or twilight sensor, will allow you to turn on and off the lights in your house or facility automatically. Thanks to its photocell chip, this product is able to detect the difference between night and day, and turn on the lights automatically with the consequent saving in the electricity bill. In addition, you can also install it outdoors, as long as it is sheltered, so you can control the lights in your garden without having to get out of bed.
Convenience and savings on your electricity bill
Installing our twilight sensor on your terrace or garden will result in significant savings on your electricity bill, as your lighting will only operate when it is needed. In addition, your visitors will be impressed to see this automatic system of switching on and off lights.
Nominal Voltage (V)
230
Maximum power (W)
2300
IP
IP44
Dimensions (mm) Lxlxh
Ø80x105
Frequency (Hz)
50 - 60
Detection range (m)
más de 40 LUX: OFF
over 40 LUX: OFF
over 40 LUX: OFF
Orientable
No
Weight (g)
150
Material
Plastic
Use Outdoor
Yes
Temperature range
-20°C ~ +40°C
Frequency of use
Intensive
Energy efficiency class
A+ (2021)
Certificates
CE
ROHS
ROHS
Warranty
According to legal guarantee: 2 years
Questions
| P: Question: | Can't this sensor regulate the brightness level to be activated? In order to not only turn on the lamp when it gets dark, but also when it is cloudy. |
|---|
| R: Answer: | This model does not allow to regulate the activation level, when the set level is exceeded, the sensor is activated (about 40Lx). |
|---|
| P: Question: | The light comes on when it gets dark is the right thing to do with this device, but I want it to power the load when it's daytime only. |
|---|
| R: Answer: | We only have this twilight model available. You should see the option of connecting a 220vac relay to the sensor and use the normally closed output in standby to activate the load. |
|---|
| P: Question: | I'd like to buy one or two sensors, but I can only pay by MB or bank transfer so that I can start buying other items in the future thank you |
|---|
| R: Answer: | Mr. Manuel, please complete the purchase with the bank transfer option, then send an email to comercial@barcelonaled.pt and ask us for the Multibanco reference and we will send it to you as soon as possible. |
|---|
| P: Question: | Hello ktal... I know how many watts it is ? |
|---|
| R: Answer: | Hi Omar, how are you? The 180º IP44 photoelectric twilight sensor switch has a maximum power of 2300 w. Greetings, |
|---|
| P: Question: |
Good morning, I would like to put this sensor in the distributor of the house, so that when I open the door to the street, I can turn on an ambient light (hall). Is this the product I am looking for? |
|---|
| R: Answer: | The twilight sensor works automatically when it gets dark and turns off when light is received. You are looking for a motion sensor, which detects the presence or passage in motion. |
|---|
| P: Question: | Does it have a dimmer to turn it on with more or less light? |
|---|
| R: Answer: | The sensor does not allow you to adjust the brightness, it only acts as an on/off switch. In any case, if the lamp allows dimming, you can install a dimmer and control the luminous flux independently. |
|---|
