SKU:SK-V1-K
Has superado el límite de unidades
In stock 44 units
Data sheet

"Skydance" manual dimmer with rotary dial for 12-48V DC single colour LED luminaires, with 1 channel output.

Allows PWM frequency variation between: 500Hz, 2kHz, 8kHz or 16kHz and selection of linear or logarithmic dimming curve.

It incorporates a digital display to visualize the adjustment parameters.

It offers a smooth dimming from 0 to 100% without flickering and is compatible with single-color RF 2.4G "Skydance" remote controls.

Depending on the selected frequency, the manual dimmer will allow a maximum current step of up to 20A.

  • IN/OUT: 12/48V
  • Max. 20A
  • Single color
  • 1 channel
  • IP20
Shipping to Africa available
public
For any shipping requests to Africa, please contact our sales department at:  comercial@barcelonaled.com

PMW Manual Dimmer 12-48V DC - 20A

This manual dimmer is an advanced solution for controlling the intensity of light in any environment, both at home and in commercial spaces.

With its digital numeric display, it offers a clear and precise visualization of the selected dimming level, making it easy to adjust the lighting according to the needs of each situation.

This dimmer can be paired with a compatible 2.4G RF remote control (Skydance), providing additional convenience by allowing lighting control from different points within the room.

It allows choosing between a linear or logarithmic dimming curve and supports a maximum load capacity of 20A.

With four selectable PWM frequencies (500Hz, 2kHz, 8kHz, or 16kHz), this dimmer offers additional flexibility to optimize LED lighting performance and avoid potential flickering.

To ensure safety and durability, it's equipped with protectoin against overheating, overload and short-circuit.

Additionally, it offers the option to select a fade time when turning the light on or off (Light on/off fade time), with a smooth 3-second transition that provides a more pleasant and comfortable lighting experience.

Product features:

  • Input/output voltage: 12-48V DC
  • Max. current: 20A
  • 1 channel
  • Maximum power: 240W (12V) / 480W (24V)
  • PMW frequencies: 500Hz, 2kHz, 8kHz or 16kHz
  • Compatibility with Skydance RF controls
  • Indoor use: IP20
  • Dimensions: 107 X 75 X 38 mm
Nominal Voltage (V)
12-48VDC
IP
IP20
Dimensions (mm) Lxlxh
107 X 75 X 38
Control system
0-10V
Use Outdoor
No
Temperature range
-30°C ~ +55°C
Certificates
CE
ROHS
Warranty
5 years
