Single color dimmable controller - AC TRIAC RF Dimmer - 2 channels 1,2A/ch - 100-240VAC Sunricher - Perfect RF

The Sunricher AC TRIAC Dimmer controller features a slim design that allows for multiple applications in both domestic and commercial environments.

Through a remote control, this controller can turn on, turn off or dim single color LED luminaires connected to the mains.

It supports resistive and capacitive loads and is TRIAC dimmable.

It has two channels (both channels work together) with a maximum load of 1.2 A per channel:

Dimmable LED lamps: maximum load: 2 channels x 60W -100V output, 2 channels x 144W - 240V output. Due to the variety of LED lamp designs, to determine the maximum number of lamps to be connected per channel, the power factor must be taken into account.

Dimmable LED drivers: Maximum load 2 channels x 60W - 100V output, 2 channels x 144W - 240V output. Maximum allowable number of drivers per channel is 60W/144W divided by the rated power of the driver board.

It is suitable for use in a single zone or in different zones where multiple receivers are used.

This RF controller also features an innovative user-adjustable minimum brightness function that allows the brightness to be dimmed from 0 to 100%.

It is compatible with both RF remote controls and wall dimmers (PERFECT RF). In addition, if connected to a WIFI-RF converter, it can be controlled via an app from any smartphone running IOS or Android.

COMPATIBLE REMOTE CONTROL MODELS: SR-2833K5, SR-2833K1/K2, SR-2836R.
